Wellington ECR® Motors for Commercial Refrigeration
Trusted and innovative refrigeration controllers
Compare models at a glance or dive into individual specs. Select a model to find the Wellington motor that's right for your next project.
Compare
Model
ECR 2 | 26W
Model
ECR 2 | 13W
Speed (rpm)
700-2300rpm
Speed (rpm)
300-1800rpm
Max output power
26W
Max output power
13W
Efficiency
74%
Efficiency
70%
Multi-speed + reversible
3 speed
Multi-speed + reversible
3 speed
Variable speed
Yes
Variable speed
Yes
Programmable
Yes
Programmable
Yes
Voltage
100-240V
Voltage
100-240V
Frequency
50-60Hz
Frequency
50-60Hz
Ingress protection
IP67
Ingress protection
IP67
HC compliant
Standard
HC compliant
Standard
ATEX compliance
Standard
ATEX compliance
Standard
Food grade materials
Optional
Food grade materials
Optional
Specifications
Downloads
ECR 2 | 26W Specifications
Engineered for maximum performance in demanding conditions, the ECR 2 26W smart refrigeration motor provides industry-leading 74% efficiency, IP67 durability, global voltage compatibility and programmable control.
Speed
Efficiency
Max output power
Voltage
Frequency
Ingress protection
Food grade materials
Multi-speed + reversible
Customer programmable
Variable speed
ATEX compliance
Hydrocarbon refrigerant approved
Our solutions
Motors that power a complete ecosystem
AoFrio’s brushless direct current (BLDC) fan motors are part of the only end-to-end smart fleet management system delivered by a single partner. Paired with our IoT devices and AoFrio iQ platform, Wellington motors provide a variable fan speed solution to optimize energy usage beyond base motor efficiency.
Testimonials
What our clients are saying
"We would like to share our experience working with the AoFrio team, which has been very positive. We especially highlight the support we have received from all the areas involved, as they have always been attentive to our needs. Throughout this long journey, we have significantly improved the control of our equipment thanks to the tools we are using."
Bebidas Del Paraguay
Cold Chain Supervisor
Proven quality - Wellington ECR motors
Get in touch
Discover resources
Frequently asked questions
With up to 74% efficiency, the ECR motor translates into lower costs and better emissions performance, helping your retail partners reduce operational costs and supporting your sustainability targets.
They offer commercial refrigeration OEMs several benefits that help them meet evolving regulatory demands and deliver market-leading coolers:
- Exceptional efficiency (up to 74%), reducing energy costs, cutting carbon emissions and helping to meet regulatory requirements
- Proven reliability with 10-year design life and IP67 protection, minimizing warranty claims, failures and maintenance
- Global voltage compatibility, universal mounting and programmable controls, reducing SKUs, simplifying inventory, and accelerating design cycles and time-to-market.
They can power condenser and evaporator fans across a range of commercial refrigeration applications, such as bottle coolers, display cabinets (including plug-in and remote display cabinets), multi-deck refrigerators, and more. Wellington motors are primarily used as fan motors in refrigeration circuits, but are equally well-suited for agitator motors in ice bank systems and for fan motors in heat pump water heaters.
Wellington ECR motors are the foundation of AoFrio INSIDE, our integrated hardware solution combining motors, SCS controller, and Gateway. Together, they deliver validated energy savings of up to 47%, superior temperature control, and reduced maintenance costs. Field-tested in real-world cold drink equipment fleets, INSIDE accelerates your ROI and Net Zero goals.
Yes. Our Wellington ECR 2 motor range has universal voltage compatibility (100-240V), which eliminates the need to hold regional variants, simplifying inventory and accelerating integration.
Advanced electronics, high-level protection up to IP67, long-life bearings and built-in overload features provide Wellington ECR motors’ durable, low-maintenance operation.
Yes, they exceed global efficiency targets and environmental compliance requirements.
AoFrio offers expert local technical assistance and training alongside written support documentation, so you can get the most out of your motors.
